The Wisconsin Center

Downtown Milwaukee’s state-of-the-art convention facility, is a design-build project which highlights GRAEF’s expertise in innovative structural design. The building is three levels and covers a four-square-block area. The third level exhibit space is large enough to hold two 747s airplanes or 550 city buses and is accessible to semi-trailer trucks for loading and unloading of exhibit materials.

The design group, collectively known as D.4 Associates, consisted of GRAEF; Affiliated Engineers, Inc.; Engberg Anderson Design Partnership; and Thompson Ventulett, Stainback & Associates. The construction team of Clark/Hunzinger completed the design-build team.

Constructed on a landfill site, the Wisconsin Center uses a mixed structural system of cast-in-place concrete, precast concrete, and steel to support an excess of 350 million pounds. The exhibit hall is designed to support a live load of 350 pounds per square foot. Additionally, part of the exhibit hall spans 140 feet over a ballroom, making vibration analysis critical. The roof is a long span structure containing 14-foot deep trusses and spanning up to 180 feet.

Awards:

  • ACEC WI – Engineering Excellence, Honor Award
  • WRMCA – Best of Region
  • WRMCA – Best Municipal Project
  • Wisconsin Concrete Masonry Concrete Trowel Award
  • DBIA Best Public Project ( National award)

Other Projects

NFHC 01

Nelson Family Heritage Crossing

Potawatomi Rec Center

Forest County Potawatomi Recreation Center

CC

Christ Church Mequon

MSO

Milwaukee Symphony Orchestra Grand Theater

Hart Park Interpretive Playground

Hart Park Interpretive Playground

Jaycee Park-header

Jaycee Park Master Plan

Location

Milwaukee, WI



Project Data

$170 Million Project Cost
700,000 Square Feet



GRAEF Services

Structural Engineering
